SemiLEDs N3535U-UNL1-A1G11H UV Led Light 3.4-3.6V 350-1000MA 410NM - 420NM

Technical Parameters:

• Power: 3W
• MODEL: SemiLEDs N3535U-UNL1-A1G11H
• Voltage: 3.4-3.6V
• Current: 350-1000MA
• Wavelength: 410-420NM/420-425NM
• Radiometric Power: 900-1100mW
• Beam Angle: 125°

Market applications using UV LEDs are diverse and represent a significant opportunity for any LED packager or integrator. Traditional mercury lamps have many disadvantages that limit UV applications, and mercury is a notorious pollutant. Features of the LED including form factor, wavelength and lifetime, add flexibility to UV applications. SemiLEDs’ portfolio of mercury free UV products will enhance and in some cases revolutionize the way applications are built in UV market segments such as Curing, Currency/Document Verification, Tanning, Medical, and Sterilization.
All SemiLEDs UV chips are made using our patented metal alloy vertical MvpLED™ technology. This allows for
maximum heat transfer from the junction to the board or heat sink. These features along with the optical
advantages facilitate designs using higher drive currents to maximize light density.

UV LED Applications:

1. LED phosphor lighting
2. UV air purifier
3. Medical applications
4. UV activated applications
5. Counterfeit detection
6. Special chemical detection
7. High resolution optics

Package Included:

• 1PC X Semileds UV Led Light
