12W Epileds RGBW RGB White 4-Chip High Power LED Light 20mm Star PCB Board

Previous Next

12W Epileds RGBW RGB White 4-Chip High Power LED Light 20mm Star PCB Board

Be the first to review this product

SKU:KW-EPRGBW (In stock)

Size (mm) 20MM
CCT/wavelength 620-630nm (red) 520-535nm (green) 450-465nm(blue) 6000-6500k(white)
Product voltage 2.25-2.6V (red) 3.3-3.9V (green) 3.1-3.7(blue) 3.1-3.7(white)
Maximum drive current (A) 1.0
MAX luminous flux(LM) 87.4 (red) 114 (green) 39.8(blue) 100(white)
Maximum power (W) 12
Viewing angle (degrees) 130

$2.00

Details

Technical Parameters:

PCB Size (mm) : 20MM
CCT/wavelength : 620-630nm (red) / 520-535nm (green) / 450-465nm(blue) / 6000-6500k(white)
Product voltage: 2.25-2.6V (red) / 3.3-3.9V (green)/ 3.1-3.7(blue) / 3.1-3.7(white)
Maximum drive current (A) : 1.0
MAX luminous flux(LM) : 87.4 (red) / 114 (green) / 39.8(blue) / 100(white)
Maximum power (W) : 12
Viewing angle (degrees) :130

Package Included:

1PC X Epileds RGBW Led
